Equipment KTS 5500 KTS 8500 KTS 11000 KTS 10600 KTS 13000
Maximum load, t 5,5 8,5  11 10,6  13
Effective load area, m2 1,06 1,80 2,30 2,00 2,80
Dimensions of frame of special steel, mm 120x80x6 180x180x6 180x180x8 2x(200x100x8) 2x(200x100x8)
Standard axle, mm 60x60 70x70 80x80 80x80 80x80
Tyres standard, mm 400/60x15,5 400/60x15,5 400/60x15,5 400/60x15,5 520/50x17
Stakes 3 2 3 4 4
Steering cylinders - 1 2 2 2
Weight, kg 1245 2391 2840 2609 3100
К.T.S. Hydraulic crane  KTS 5400S KTSK640 KTS670 KTS750
 KTS Comfort joint to symplify work _ + + +
Telescopic support legs + _ _ _
Hydraulic support legs _ + + +
Gross lifting force of crane (kNm) 25 35  50  50
Max crane reach, m 5,39 6,43 6,69 7,47
Grapple lifting capacity of horizontal crane arm outreach at 4m, kg 575 824 1178 1168
Grapple lifting capacity at max reach, kg 315  330 426  246
Тelescopic reach, m _ 1,2 1,2 2,0
Slewing angle, grad.o 370 370 370 370
Recommended pump capacity, l/min 15-50  20-60  20-60  20-60
Weght, kg
(incl. grapple and rotator)
482 934  992  1059
